Ingersoll Rand Screw Air Compressor (37-75KW / 50-100HP)

Regular price
$0.00
Sale price
$0.00
Regular price
Sold out
Unit price
per

Customized products, please inquire before placing an order.
Basic Info.



Model NO.:
37-75KW / 50-100HP
Power Source:
AC Power
Configuration:
Stationary
Type:
Screw
Lubrication:
Lubricated
Mute:
Yes
Compress Stage:
Single
Power Supply(V/pH/Hz):
380\/3/50(Can Be Changed)



Product Description
1. A rugged and reliable air compressor is what most people desire. If this is your priority then look no further than Ingersoll Rand's 37-75kW / 50-100HP rotary air compressors. With time proven, integral gear drive Intellisys control system, and long life Ultra Coolant, the Ingersoll Rand, single stage, contact cooled rotary compressor is the one that you can count on for years to come

2. Digital Control System
Delivered capacity of the compressor is regulated by the Intellisys microprocessor controller and regulator. The intuitive controller provides all the information you need at the touch of a button. You can rest assured that your compressor will be under reliable control needing minimum maintenance.

3. Higher Ambient Rating
Rated to operate continuously at high ambient temperatures of 115 (46). This means fewer nuisance shutdowns due to summer heat or reduced susceptibility to operating in dirty conditions.

4. Advanced Air-end Design
At the heart of the compressor is our conservatively loaded, rugged and highly reliable air-end which is close coupled to an integrated drive system. This gear drive arrangement eliminates the need for couplings and is known throughout the industry for its trouble-free operation with minimal maintenance.

5. SSR Ultra Coolant
Designed specifically for rotary screw air compressors, Ultra Coolant minimizes maintenance costs by extending the operating life of the compressor and maximizing the time between changes: 8, 000 hours or 2 years.
Model
Frequency (Hz)
Rated Pressure (barg / psig)
Nominal Power (kW / hp)
Flow                  (m3min / cfm)
Length (cm / in)
Width (cm / in)
Height (cm / in)
Weight            (kg / lbs)
ML 37
50
7.5 / 109
37 / 50
6.1 / 215
170 / 67
160 / 63
170 / 67
907 / 2000
MM 37
50
8.5 / 123
37 / 50
5.9 / 208
170 / 67
160 / 63
170 / 67
907 / 2000
MH 37
50
10 / 145
37 / 50
5.6 / 198
170 / 67
160 / 63
170 / 67
907 / 2000
MXU 37
50
14 / 203
37 / 50
4.8 / 169
170 / 67
160 / 63
170 / 67
907 / 2000
ML 45
50
7.5 / 109
45 / 60
7.4 / 261
170 / 67
160 / 63
170 / 67
953 / 2100
MM 45
50
8.5 / 123
45 / 60
7.1 / 251
170 / 67
160 / 63
170 / 67
953 / 2100
MH 45
50
10 / 145
45 / 60
6.5 / 230
170 / 67
160 / 63
170 / 67
953 / 2100
ML 55
50
7.5 / 109
55 / 75
10.1 / 357
170 / 67
160 / 63
170 / 67
1270 / 2800
MM 55
50
8.5 / 123
55 / 75
9.1 / 321
170 / 67
160 / 63
170 / 67
1270 / 2800
MH 55
50
10 / 145
55 / 75
8.3 /293
170 / 67
160 / 63
170 / 67
1270 / 2800
MJ 55
50
11.4 / 165
55 / 75
7.6 / 268
170 / 67
160 / 63
170 / 67
1270 / 2800
MF 75
50
7.1 / 103
75 / 100
14.7 / 519
170 / 67
160 / 63
170 / 67
1315 / 2900
ML 75
50
7.5 / 109
75 / 100
13 / 459
170 / 67
160 / 63
170 / 67
1315 / 2900
MM 75
50
8.5 / 123
75 / 100
12.1 / 427
170 / 67
160 / 63
170 / 67
1315 / 2900
MH 75
50
10 / 145
75 / 100
11 / 388
170 / 67
160 / 63
170 / 67
1315 / 2900
MJ 75
50
11.4 / 165
75 / 100
10.1 / 357
170 / 67
160 / 63
170 / 67
1315 / 2900
XFE 50
60
6.9 / 100
37 / 50
6.5 / 231
170 / 67
160 / 63
170 / 67
907 / 2000
EPE 50
60
8.6 / 125
37 / 50
5.9 / 208
170 / 67
160 / 63
170 / 67
907 / 2000
HPE 50
60
9.7 / 140
37 / 50
5.6 / 199
170 / 67
160 / 63
170 / 67
907 / 2000
EX 60
60
6.9 / 100
45 / 60
7.8 / 275
170 / 67
160 / 63
170 / 67
953 / 2100
EP 60
60
8.6 / 125
45 / 60
6.9 / 244
170 / 67
160 / 63
170 / 67
953 / 2100
HPE 60
60
9.7 / 140
45 / 60
6.3 / 224
170 / 67
160 / 63
170 / 67
953 / 2100
XF 75
60
6.9 / 100
55 / 75
10.9 / 386
170 / 67
160 / 63
170 / 67
1270 / 2800
EP 75
60
8.6 / 125
55 / 75
9.4 / 332
170 / 67
160 / 63
170 / 67
1270 / 2800
HP 75
60
9.7 / 140
55 / 75
8.5 / 299
170 / 67
160 / 63
170 / 67
1270 / 2800
XP 75
60
11.4 / 165
55 / 75
7.0 / 248
170 / 67
160 / 63
170 / 67
1270 / 2800
XF 100
60
6.9 / 100
75 / 100
14.0 / 495
170 / 67
160 / 63
170 / 67
1315 / 2900
EP 100
60
8.6 / 125
75 / 100
12.6 / 446
170 / 67
160 / 63
170 / 67
1315 / 2900
HP 100
60
9.7 / 140
75 / 100
11.7 / 412
170 / 67
160 / 63
170 / 67
1315 / 2900
XP 100
60
11.4 / 165
75 / 100
10.1 / 358
170 / 67
160 / 63
170 / 67
1315 / 2900
